Opis
Audio Technica ATW13F mikrofon bezprzewodowy.
System ATW-13F jest wyposaony w nadajnik rczny o mocy nadawczej 10mW. Wkadka pojemnociowa o charakterystyce kardioidalnej zapewnia doskonae brzmienie.
| Overall System | |
|---|---|
| Operating Frequencies | 24 – 831 MHz, 863 – 865 MHz |
| Number Of Channels | 2 x 4 frequencies |
| Frequency Stability | +/- 0.005%, Phase lock loop frequency control |
| Modulation Mode | FM |
| Frequency Response | 60 Hz – 16 kHz |
| Operating Range | 60m, typical |
| Receiver | |
|---|---|
| Receiving System | Antenna switching diversity |
| Image Rejection | 55dB minimum |
| Dynamic Range | HH: 108 dB, BP 103 dB (@ max deviation) |
| Sensitivity | 10dBV (S/N 60dB @ 20 kHz deviation) |
| Total Harmonic Distortion | <1% - 20 kHz deviation @ 1 kHz |
| Audio Output Unbalanced | -2dBV |
| Audio Output Balanced | 4dBV |
| Output Connectors (Microphone) | Balanced: XLRM-type |
| Output Connectors (Instrument) | Unbalanced: 6.3 mm mono jack |
| Maximum Output Level | Mic / Line (0 / -20dB) |
| Antenna Input | BNC type, 50 – BIAS voltage 12V DC 100mA each |
| Dimensions | 200 mm x 42 mm x 122 mm (W x H x D) |
| Weight | 418 g without accessories |
| Accessories Included | AC Adapter, Antennas, Rack mount adapter, protective carrying case |
| Handheld Transmitter | |
|---|---|
| RF Power Output | 10 mW |
| Spurious Emissions | Following national regulatios |
| Microphone Element | Condenser Cardioid |
| Battery Type | Two 1.5V AA alkaline |
| Battery Life | 10 hours – depending on battery type and use pattern |
| Dimensions | 268 mm long – 52 mm (diameter) |
| Accessories Included | Stand clamp |
